IndustrialWirelessDigital Input Output Transc Specification

Product Type
Industrial Wireless Digital Input Output Transceiver

Storage Channel
16

Talk Range
1 km (Open Area)

Interface
RS485/RS232/TTL

Material
ABS Plastic

Transmission Power
100mW

Transmission Rate
1200/2400/4800/9600/19200 bps

Digital Input Channels
4

Sensitivity
-121 dBm

Digital Output Channels
4

Operating Temperature
-10C to 60C

Application
Remote monitoring, industrial automation, data transmission

Indicator Lights
Power, Signal, I/O Status

Protection Grade
IP40

Relative Humidity
10% ~ 90% RH (Non-condensing)

Mounting Type
Panel Mounting

IndustrialWirelessDigital Input Output Transc Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About IndustrialWirelessDigital Input Output Transc

FEATURES

ISM band 868 MHZ
Measuring input: PT100/PT1000
Open Air Range 1Km
Battery status Monitoring
Rechargeable Battery
Easy to install
Wireless transmission
Low power consumption
Configurable transmission intervals

APPLICATION SCOPE

Process Solutions
Pharma Industry
HVAC Systems
Food Industry
Cold chain Management
Environmental Monitoring
Industrial IoT (IIoT) Applications
Chemical Chambers
Utilities measurement

Transmitter

Battery: 3600mAH, rechargeable lithium ION
Transmission Power : 0 to 20dbM, configurable.
Transmission Range: Line of Sight 1KM.
Compatibility: 2 Wire, 3 Wire 4 Wire, PT100.
Ambient Temperature: -30 to +85 deg C
Communication Interval : 1s to 3600s Configurable
Optional: Transmit of change of temperature.
ADC: 15-bit ADC, has a 0.5 deg C accuracy over a -200 deg C to 850 deg C range to service these more critical temperature challenges.
Independent communication channels ensure 100s of devices work simultaneously without cross-talk.
Transmission parameters: Unique ID, Battery Voltage and Temperature.
Customizable and plug and play interface.
Encrypted communication with acknowledgement for each transaction.

Receiver:

Input: 12 to 36V DC.
Protections: Isolated Power supply, Reverse voltage and Short circuit Protection.
Interfaces: Analog output channel 1 No( 4 to 20 mAmp)
Isolated RS485 Modbus RTU
Supports Many-to-one Mode and gives data in RS485 Interface.
Supports 4 Wire and 3 Wire Mode.
Ambient Temperature: -30 to +85 deg C
Display Parameters: Temperature, Errors, output mAmps.
Inbuilt Relay can be configured with a Low Battery Alert.
Independent communication channels ensure 100s of devices work
simultaneously without cross-talk.
Encrypted communication with acknowledgement for each transaction.

Discover a monumental advancement in industrial automation with the IndustrialWirelessDigital Input Output Transc, now available at a bargain for advance purchase. This popular device features 4 digital input and 4 output channels, ideal for remote monitoring and data transmission in demanding environments. Enjoy optimum performance with an external omni-directional antenna, transmission power up to 100mW, and a talk range of 1 km. Robust protection (IP40), comprehensive indicator lights, and seamless RS485/RS232/TTL interfaces make this a marvelous solution for modern industries across India.

Versatile Applications and Standout Features

Ideal for remote monitoring, automation, and reliable data transmission, the IndustrialWirelessDigital Input Output Transc excels in industrial sites, manufacturing floors, and infrastructure projects. Its panel mounting, ABS plastic body, and wide operating temperature range provide superior adaptability. Key features include 16 storage channels, indicator lights for status and signal, and IP40 protection, ensuring dependable operation even in variable conditions. This device is engineered to meet rigorous industrial demands, delivering uninterrupted connectivity and control.

Reliable Supply, Certified Valuation, and Flexible Policy

Enjoy optimum valuation through our efficient supply network, ensuring swift dispatching of every order. Certified for standard compliance, the product guarantees a dependable exchange between supplier and user. We provide ample supply capacity so that large-scale industrial requirements are always met. Flexible sample policies enable businesses to experience its value prior to commitment, fostering trust and transparency. Partner with a supplier in India who values reliability, timely delivery, and customer-oriented exchange processes.

FAQ's of IndustrialWirelessDigital Input Output Transc:

Q: How does the IndustrialWirelessDigital Input Output Transc benefit remote monitoring?

A: This device allows seamless wireless data transmission over a 1 km open area range, making remote monitoring efficient and reliable, with real-time status updates via indicator lights.

Q: What mounting options are available for this device?

A: The device supports panel mounting, making installation straightforward and stable in a variety of industrial settings.

Q: Where can the IndustrialWirelessDigital Input Output Transc be used?

A: It is suitable for industrial automation, manufacturing facilities, and infrastructure projects where automated digital I/O and wireless communication are essential.

Q: What is the process for obtaining a sample unit?

A: You can request a sample through our supplier's flexible sample policy, which enables user evaluation before bulk exchange or purchase.

Q: When is advance purchase recommended for this product?

A: Advance purchase is recommended for customers needing guaranteed swift dispatch and large volume supply, especially for time-sensitive projects.

Q: How is reliable data transmission ensured?

A: With selectable transmission rates, external omni-directional antenna, and sensitivity of -121 dBm, consistent data transmission is maintained despite industrial environmental challenges.
